Name: MF series pulse bag filter

Keywords: MF series pulse bag filter
Description: Product introduction  MF- II square pulse bag filter is modified and modified on the basis of MF- type I.Performance characteristics  In addition to its characteristics such as high dust removal efficiency, large amount …

Details

Product introduction
  MF- II square pulse bag filter is modified and modified on the basis of MF- type I.
Performance characteristics
  In addition to its characteristics such as high dust removal efficiency, large amount of air handling, stable performance, convenient operation and maintenance, it also has the advantages of better use effect, less powder accumulation and wide application range than the I type.
Adaptive material
  Widely used in food, food, feed, metallurgy, chemical, building materials, pharmaceuticals and other industries of ventilation, dust collection and dust recovery.
Technical specifications

Parameter

Model

MF48

MF60

MF72

MF84

MF96

MF108

MF120

Filtration area（m2）

36.2

45.2

54.3

63.3

72.4

81.4

90.5

Number of filter bags

48

60

72

84

96

108

120

Filtration rate (m3/h)

6510-8680

8130-10840

9770-13000

11400-1520

13000-17370

14650-19530

16290-21700

Solenoid valve quantity（只）

8

10

12

14

16

18

20

Power (kw)

1.1

1.1

1.1

1.1

1.5

2.2

2.2

Filter bag specification (mm)

120×2000

Filtration velocity (m/min)

3-4

leak out rate (%)

≤5

Injection pressure (Mpa)

＞0.4-0.6

Equipment resistance (Pa)

＜1200

Dust removal efficiency (%)

≥99.9（Select the suitable filter material according to the dust characteristics

  ）


Technical specifications

Parameter

Model

MF48

MF60

MF72

MF84

MF96

MF108

MF120

A

3530

3530

3530

3530

3530

3530

3530

B

3287

3287

3287

3287

3287

3287

3287

C

2552

2552

2552

2552

2552

2552

2552

D

1160

2260

1160

1160

1160

1160

1160

E

1350

1650

1950

2250

1350

2850

3150

F

1350

1350

1350

1350

1350

1350

1350

G

635

635

635

635

635

635

635

H

325

475

625

775

925

1075

1225

I

1586

1586

1586

1586

1586

1586

1586

J

790

790

790

790

850

850

850

K

824

824

824

824

824

824

824

M×N

400×500

500×500

600×500

700×600

700×600

800×600

800×600

P×Q

432×530

530×530

630×530

728×630

728×630

832×630

832×630

R×S

1050×1050

1350×1050

1650×1050

1950×1050

2250×1050

2250×1050

2850×1050
