Performance characteristics
Cylinder loading of the driving shaft driven, as the cycle of translation, turning and other complex motion, which makes the material along the barrel body three to the complex movement, so as to realize the mutual flow of various materials, diffusion, accumulation, doped to achieve uniform mixing purposes.
Adaptive material
◎The mixing barrel multi direction movement of material without centrifugal force, without gravity segregation and stratification accumulation phenomenon, each component may have poor weight ratio, high mixing rate, is the ideal product in mixing machine.
◎The loading rate of the cylinder is large, the maximum is 90% (ordinary mixer is only 50%), the efficiency is high, and the mixing time is short.
◎The tube is made of circular arc and is polished by precise polishing.
◎Used in pharmaceutical, chemical, food, light industry, electronics, machinery, mining and metallurgy,
◎High homogeneity mixing of powdery and granular materials in national defense industry and various scientific research units.
Schematic drawing
Technical specifications
|
Model |
SYH-5 |
SYH-15 |
SYH-50 |
SYH-100 |
SYH-200 |
SYH-400 |
SYH-600 |
SYH-800 |
SYH-1000 |
SYH-1200 |
SYH-1500 |
SYH-2000 |
|
Volume of material barrel (L) |
5 |
15 |
50 |
100 |
200 |
400 |
600 |
800 |
1000 |
1200 |
1500 |
2000 |
|
Maximum charge volume (L) |
4.5 |
13.5 |
45 |
90 |
180 |
360 |
540 |
720 |
900 |
1080 |
1350 |
1800 |
|
Maximum charge weight (kg) |
1.5-2.7 |
4-8.1 |
15-27 |
30-54 |
50-108 |
100-216 |
150-324 |
200-432 |
250-540 |
300-648 |
400-810 |
500-1080 |
|
Spindle speed (r/min) |
0-20 |
0-20 |
0-20 |
0-20 |
0-15 |
0-15 |
0-13 |
0-10 |
0-10 |
0-9 |
0-9 |
0-8 |
|
Motor power（kw） |
0.25 |
0.37 |
1.1 |
1.5 |
2.5 |
4 |
5.5 |
7.5 |
11 |
11 |
15 |
18.5 |
|
Size（mm） |
600×1000 |
800 ×1200 |
1150 ×1400 |
1250 ×1800 |
1450 ×2000 |
1650 ×2200 |
1850 ×2500 |
2100 ×2650 |
2150 ×2800 |
2000 ×3000 |
2300 ×3200 |
2500 ×3500 |
|
Weight（kg） |
100 |
200 |
300 |
800 |
1200 |
1200 |
1500 |
1700 |
1800 |
2000 |
2400 |
3000 |
Note: the material density shall be 0.6g/cm3. If it exceeds, please indicate when ordering.
