Name: DSH series double screw cone mixer

Keywords: DSH series double screw cone mixer
Description: Product overview By the screw of the rotation, so that the material in the cone of composite movement, there are four main forms of motion:1. The spiral moves along the wall, so that the material moves along the cone wall in a circle;2. The spiral…

Details

Product overview
By the screw of the rotation, so that the material in the cone of composite movement, there are four main forms of motion:
1. The spiral moves along the wall, so that the material moves along the cone wall in a circle;
2. The spiral rotation causes the material to spiral upward from the bottom of the cone;
3. The compound motion of the screw and the rotation causes a part of the material to be absorbed into the spiral cylindrical surface, and at the same time, a part of the material in the spiral cylindrical surface is discharged radially to the cone at the same time by the centrifugal force of the spiral rotation;
4. The ascending material is lowered by its gravity. The four kinds of motion produce convection, shear and diffusion in the mixer, so as to achieve the purpose of rapid and even mixing.
Product features
The utility model can be provided with a fly knife, spraying and atomizing assembly to meet the requirements of a special process.
The discharge valve has two ways: manual and pneumatic.
Special material can increase the power of motor (plus heavy).
Product application
Used in chemical, pharmaceutical, pesticide, dyestuff, petroleum, metallurgy, building materials, powder and powder (solid solid), powder and liquid (solid liquid), liquid and liquid (liquid liquid) mixing, reaction, drying and cooling.
Technical specifications

Model

Unit

DSH0.3

DSH0.5

DSH1

DSH2

DSH4

DSH6

DSH10

Full volume

m3

0.3

0.5

1

2

4

6

10

Loading coefficient

0.4-0.6

Mixed material size

um40-3000

Working conditions

Dust sealing at normal temperature and atmospheric pressure

Yield per time

kg

180

300

600

1200

2400

3600

6000

power

(kw)

2.2

2.2

5.5

5.5

11

20.7

30.7

Mixing time

(min)4-10Special materials are determined by experiment

Weight

(kg)

500

1000

1200

1500

2800

3500

4500
